Felicity 12kva 48v solar INVERTER IVEM12048-II

Description

Felicity 12kva 48v solar INVERTER IVEM12048-II Price in Nigeria



Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine Felicity Solar products in Nigeria, supplying Felicity solar inverters, solar batteries, solar panels and other renewable-energy products to customers across Nigeria.



Felicity 12kva 48v solar INVERTER IVEM12048-II Price in Nigeria



The Felicity 12kva 48v solar INVERTER IVEM12048-II is a high-capacity, low-voltage off-grid inverter designed for homes, offices, businesses and other applications with substantial electricity requirements. Felicity identifies the IVEM12048-II as a 12kW, 48V, single-phase inverter with the option to create a three-phase system by connecting at least three units.



The inverter combines an inverter, MPPT solar charger and battery charger in one system. It also features an LCD interface, built-in Wi-Fi monitoring, generator compatibility and several protection functions.



Felicity 12kva 48v solar INVERTER IVEM12048-II Price Range in Nigeria



The price of the Felicity 12kva 48v solar INVERTER IVEM12048-II varies depending on the seller, exchange rate, stock availability, warranty and market conditions.



Recent Nigerian online listings place the product at approximately ₦1,012,000 to ₦1,400,000, although prices can change. One Nigerian listing recently showed ₦1,012,000, while another listed a new unit at ₦1,400,000.



Estimated Price Range: ₦1,000,000 – ₦1,450,000



For the latest selling price, availability and warranty, buyers should contact Nature Links Nigeria Limited before making payment.







Uses of Felicity 12kva 48v solar INVERTER IVEM12048-II



The Felicity 12kva 48v solar INVERTER IVEM12048-II is suitable for applications where a smaller inverter may not provide enough power.



Common uses include:



– Large homes and duplexes

– Offices

– Shops and commercial buildings

– Hotels and guest houses

– Schools

– Churches and worship centres

– Supermarkets

– Restaurants

– Computer and networking equipment

– Refrigerators and freezers

– Water pumps

– Fans and lighting

– Television and entertainment systems

– Air conditioners, subject to proper load calculation

– Other appropriately sized household and commercial appliances



Benefits of Felicity 12kva 48v solar INVERTER IVEM12048-II



1. High 12kW Output Capacity



With a rated output of 12kW, this inverter is designed for high-demand installations and can handle considerably more load than typical 3kVA, 5kVA or 8kVA systems when correctly installed.



2. 48V Battery Architecture



The 48V battery configuration provides a suitable platform for large battery banks, including compatible lithium and other supported battery technologies.



3. Dual MPPT Solar Charging



The inverter supports two solar input strings, providing flexibility when designing a larger solar array. Felicity’s specifications list maximum PV input power of 15kW for the IVEM12048-II.



4. High Battery Charging Capability



Felicity’s IVEM8–12kW-II technical information lists a maximum charging current of 240A for the IVEM12048-II, making it suitable for installations requiring substantial battery charging capacity.



5. Wi-Fi Monitoring



Built-in Wi-Fi allows compatible versions to provide mobile monitoring, giving users convenient access to important system information.



6. Generator Compatibility



The inverter can work with mains electricity or a generator. Its generator port can also be configured for smart output functionality, depending on the installation.



7. Expandable Capacity



Up to six units can be connected in parallel on supported configurations. This provides room for expansion when a larger power system is required.



8. Multiple Protection Functions



The inverter includes overload, over-temperature and short-circuit protection, along with automatic restart and cold-start functions.



Felicity 12kva 48v solar INVERTER IVEM12048-II Compatibility



The inverter can be incorporated into a properly designed system using compatible:



– 48V lithium batteries

– LiFePO4 battery banks

– Other supported battery technologies

– Solar panels within the inverter’s voltage and current limits

– Mains electricity

– Compatible generators

– Solar protection devices

– DC breakers and isolators

– AC protection equipment



For lithium battery installations, the battery voltage, BMS requirements and communication compatibility should be confirmed before installation.



Felicity IVEM12048-II Datasheet



Specification| Details

Brand| Felicity Solar

Model| IVEM12048-II

Rated output power| 12kW

Battery voltage| 48V DC

Nominal AC input| 230V AC

AC input range| 90–280V AC

Frequency| 50Hz / 60Hz auto-detection

Phase| Single phase

Three-phase capability| At least 3 units

Maximum charging current| Up to 240A, according to IVEM8–12kW-II specification

Maximum PV input power| Up to 15,000W

MPPT| Dual solar inputs

Parallel capability| Up to 6 units

Monitoring| Built-in Wi-Fi/mobile monitoring

Operating temperature| -10°C to 50°C

Protection| Overload, over-temperature and short circuit



Felicity’s official product information confirms the IVEM12048-II’s 12kW rated output, 48V DC nominal battery input, 230V AC input and 90–280V AC input range. Felicity’s IVEM8–12kW-II specifications also list 15kW maximum input power, 240A maximum charging current and parallel operation of up to six units.



How Many Solar Panels Can the Felicity 12kVA Inverter Use?



The exact number of solar panels depends on the wattage and electrical specifications of the selected panels.



Felicity’s IVEM8–12kW-II documentation lists up to 15,000W maximum PV input power for the IVEM12048-II. A technical listing also specifies a maximum DC input voltage of 500V and MPPT voltage range of 90–450V.



For example, a theoretical 15kW solar array could consist of approximately:



– 30 × 500W panels = 15kW

– 25 × 600W panels = 15kW

– 24 × 625W panels = 15kW



The actual panel arrangement must be determined from the panels’ Voc, Vmp, current ratings and the inverter’s exact MPPT limits. A qualified solar installer should design the PV strings.



Felicity 12kVA vs 8kVA Solar Inverter



The Felicity 12kVA model provides substantially more output capacity than the 8kVA IVEM model. The 8kVA option can be suitable for moderate residential loads, while the 12kVA version is more appropriate for larger homes, businesses and installations with higher simultaneous loads.



Felicity 12kVA vs 10kVA Solar Inverter



A 12kVA inverter offers more capacity than a 10kVA model, giving users additional headroom for larger loads. However, the correct choice should be based on the calculated continuous load, starting/surge requirements, battery capacity and solar generation rather than inverter size alone.



Is Felicity 12kva 48v solar INVERTER IVEM12048-II Good for a Large Home?



Yes, it can be a strong option for a large home when the system is properly designed. Its 12kW output, 48V battery architecture, dual solar inputs, high charging capacity and generator compatibility make it suitable for substantial residential backup systems.



However, appliances such as multiple air conditioners, pumping machines and heating equipment can consume significant power. A load assessment should therefore be completed before purchase and installation.



Where to Buy Felicity 12kva 48v solar INVERTER IVEM12048-II in Nigeria



For customers searching for the Felicity 12kva 48v solar INVERTER IVEM12048-II Price in Nigeria, Nature Links Nigeria Limited supplies Felicity solar inverters and related renewable-energy products from Alaba International Market, Lagos.



Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited

Call: 07049528019

WhatsApp: 09040054359

Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria

Delivery: Same-day delivery in Lagos. Same-day shipping to other states.



Customers should confirm the latest price, availability, exact model number and warranty before payment.



10 Related Felicity Solar Products



Felicity 5kVA 48V Solar Inverter Price in Nigeria, Felicity 6kVA 48V Solar Inverter Price in Nigeria, Felicity 8kVA 48V Solar Inverter Price in Nigeria, Felicity 10kVA 48V Solar Inverter Price in Nigeria, Felicity 15kVA Solar Inverter Price in Nigeria, Felicity 48V 100Ah Lithium Battery Price in Nigeria, Felicity 48V 200Ah Lithium Battery Price in Nigeria, Felicity 5kWh Lithium Battery Price in Nigeria, Felicity 10kWh Lithium Battery Price in Nigeria, Felicity Solar Panel Price in Nigeria









Conclusion



The Felicity 12kva 48v solar INVERTER IVEM12048-II is a high-capacity 12kW solar inverter designed for large residential and commercial applications, combining inverter, MPPT solar charging and battery charging functions with dual solar inputs, Wi-Fi monitoring, generator compatibility, lithium battery activation, multiple protection features and parallel expansion of up to six units. With Nigerian listings currently placing the product around ₦1,000,000–₦1,450,000, the exact Felicity 12kva 48v solar INVERTER IVEM12048-II Price in Nigeria depends on stock availability, seller, warranty and market conditions. For the latest price and supply, contact Nature Links Nigeria Limited on 07049528019, WhatsApp 09040054359, or visit F1571 UP, Alaba International Market, Lagos, Nigeria, with same-day delivery in Lagos and same-day shipping to other states.
