SMS mppt 60A charge controller

Key Features

High Tracking Efficiency: Advanced MPPT tracking algorithm delivers up to 98%–99% conversion efficiency.
Auto-Sensing Battery Voltage: Automatically detects and configures for 12V, 24V, 36V, or 48V system setups.
High PV Input Voltage: Supports a maximum photovoltaic (PV) open-circuit input voltage of up to 150V DC.
Multi-Stage Charging Protocol: Features 4-stage smart charging (Bulk, Absorption, Float, Equalization) to protect battery life.
Backlit LCD Interface: Displays real-time parameters including PV voltage, charging current, battery capacity status, and load modes.
Comprehensive Electronic Protection: Built-in safeguards against PV reverse polarity, battery overcharging, over-discharging, output short circuits, and thermal overload.
Heavy-Duty Heat Sink Chassis: Industrial-grade cooling fin design enables silent, reliable 24/7 continuous operation without noise.

Description
Reviews (0)

Description

Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine SMS products in Nigeria, supplying SMS charge controllers, solar inverters, lithium batteries, and power backup solutions to customers across Nigeria.

When planning a reliable solar installation, determining the exact SMS mppt 60A charge controller price in Nigeria is a primary step toward maximizing system efficiency. Built with advanced Maximum Power Point Tracking (MPPT) technology, the SMS 60-Amp MPPT charge controller regulates energy harvesting from solar panels to safely charge 12V, 24V, 36V, and 48V battery banks without power loss.

Price Range

The SMS mppt 60A charge controller price in Nigeria typically ranges from ₦95,000 to ₦135,000, depending on dollar exchange rate fluctuations, seller warranty packages, and order volume:

Wholesale / Bulk Price: ₦95,000 – ₦105,000
Retail Market Price: ₦110,000 – ₦135,000

Uses

Analyzing the SMS mppt 60A charge controller price in Nigeria highlights its suitability across diverse solar projects:

Residential Solar Power Systems: Controls solar power generation for homes running lighting, refrigerators, fans, and televisions.
Commercial Backup Installations: Regulates daily battery bank charging in business offices, retail outlets, and computer centers.
Telecom & Security Systems: Powers remote CCTV cameras, security lighting setups, and rural telecommunication base stations.
Agricultural Solar Pumping: Regulates solar PV input for farm water pumping and irrigation controls.

Benefits

Up to 30% Higher Energy Yield: Captures significantly more power than conventional Pulse Width Modulation (PWM) controllers.
Extended Battery Service Life: Smart multi-stage charging prevents battery overcharging and sulfation.
Cost Efficiency: Reduces the number of solar panels required by wringing maximum power out of the existing array.
Broad System Adaptability: Operates smoothly across small 12V configurations up to high-capacity 48V solar setups.

Battery Compatibility

The SMS MPPT 60A charge controller works with virtually all standard energy storage batteries:

Lithium-Ion & LiFePO4 Batteries: Fully customizable charging parameters for modern lithium battery banks.
Deep Cycle Gel Batteries: Pre-configured settings for optimal gel cell performance.
AGM (Absorbed Glass Mat) Batteries: Controlled voltage regulation prevents AGM electrolyte drying.
Tubular / Flooded Lead-Acid Batteries: Built-in equalization modes prevent cell stratification.

General Datasheet Summary

Rated Charging Current: 60 Amps
System Voltage Support: 12V / 24V / 36V / 48V (Auto Recognition)
Max PV Input Voltage (VOC): 150V DC
Max PV Input Power: 12V System: ~720W | 24V System: ~1440W | 36V System: ~2160W | 48V System: ~3120W
Peak Tracking Efficiency: ≥ 98%
Cooling Type: Heavy-Duty Passive Heat Sink Cooling
Enclosure Protection: Metal Casing

Comparison: MPPT vs. PWM Solar Charge Controllers

Feature	SMS 60A MPPT Controller	Standard 60A PWM Controller
Efficiency Rate	95% – 98% High Yield	65% – 75% Average Yield
PV Input Voltage	High VOC Support (Up to 150V)	Low VOC Support (Usually < 50V)
Cold Weather Harvesting	Excellent tracking adjustments	Drops output significantly
Overall Energy Output	Up to 30% more solar power	Standard baseline output

Where to Buy Genuine SMS MPPT Charge Controllers in Nigeria

To ensure you get original equipment backed by factory performance and full warranty coverage, buy directly from Nature Links Nigeria Limited.

Checking the current SMS mppt 60A charge controller price in Nigeria before purchase ensures you get high energy value for your solar power investment.

Related Items (Price in Nigeria)

Felicity 60A MPPT Charge Controller Price in Nigeria, PowMr 60A MPPT Charge Controller Price in Nigeria, SRNE 60A MPPT Charge Controller Price in Nigeria, Sunfield 60A MPPT Charge Controller Price in Nigeria, Must 60A MPPT Charge Controller Price in Nigeria, Fangpusun 60A MPPT Charge Controller Price in Nigeria, Suoer 60A MPPT Charge Controller Price in Nigeria, Luminous 60A MPPT Charge Controller Price in Nigeria, Outback 60A MPPT Charge Controller Price in Nigeria, Prag 60A MPPT Charge Controller Price in Nigeria

SEO Conclusion

Determining the standard SMS mppt 60A charge controller price in Nigeria allows solar installers and property owners to invest confidently in a high-efficiency power management unit. The SMS 60A MPPT controller provides robust voltage conversion, high PV input handling, and smart battery protection designed for long-term solar projects. Contacting Nature Links Nigeria Limited guarantees authentic SMS products, valid warranties, competitive pricing, and fast delivery across Nigeria.

Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited Call: 07049528019 WhatsApp: 09040054359 Visit Their Shop Address: F1571 UP, Alaba International Market. Lagos. Nigeria Delivery: Same Day Delivery in Lagos. Same Day Shipping to Other States.
