UNI-T Coating Thickness Gauge UT343D

Key Features of UNI-T UT343D

Brand: UNI-T
Model: UT343D
Product Type: Coating Thickness Gauge
Measuring Range: 0–1250 µm
Accuracy: ±(3%H + 1) µm
Resolution: 0.1 µm from 0–99.9 µm; 1 µm from 100–1250 µm
Metal Types: Ferrous and non-ferrous
Measurement Methods: Single and continuous
Measurement Modes: Maximum, minimum and average
Display: 2.0-inch TFT LCD
Display Resolution: 320 × 240 pixels
Data Storage: Up to 500 groups
Quick Test Mode: Yes
LED Alarm: Yes
Audio Alarm: Yes
USB Communication: Yes
PC Analysis Software: Included
Auto Power Off: Yes
Low-Battery Indication: Yes
Power: 2 × 1.5V AA batteries
Net Weight: Approximately 175g
Dimensions: 153.5 × 64.5 × 41mm

Description
Reviews (0)

Description

UNI-T Coating Thickness Gauge UT343D Price in Nigeria

Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine UNI-T coating thickness gauges, electrical test instruments, measuring equipment and inspection tools in Nigeria, supplying UNI-T test and measurement products to customers across Nigeria.

UNI-T Coating Thickness Gauge UT343D Price in Nigeria

The UNI-T Coating Thickness Gauge UT343D Price in Nigeria depends on supplier, availability, import costs, exchange rates and the accessories included with the instrument.

The UNI-T UT343D is a digital coating thickness gauge designed to measure coatings on both ferrous and non-ferrous metal materials. It has a measuring range of 0–1250 µm, supports single and continuous measurement, and provides maximum, minimum and average readings. UNI-T also specifies a quick-test function with LED and audio alarms for checking whether a coating falls within a preset thickness range. (UNI-T Meters)

These specifications are from UNI-T’s official UT343D product information. (UNI-T Meters)

UNI-T Coating Thickness Gauge UT343D Price Range in Nigeria

The UNI-T Coating Thickness Gauge UT343D Price in Nigeria may fall within an indicative range of approximately ₦180,000 – ₦400,000, depending on availability, supplier, importation costs, exchange rates and package contents.

Because the official UNI-T product page currently lists the UT343D as out of stock, availability can affect Nigerian pricing. (UNI-T Meters)

When comparing the UNI-T Coating Thickness Gauge UT343D Price in Nigeria, buyers should consider:

Measuring range
Accuracy
Resolution
Ferrous/non-ferrous compatibility
Data-storage capacity
Display quality
Quick-test function
USB communication
PC software
Included accessories
Warranty/support
Delivery costs

Confirm the current price and availability before placing an order.

Uses of UNI-T UT343D Coating Thickness Gauge

The UT343D can be used for measuring the thickness of suitable coatings applied to metal surfaces.

Common applications include:

Paint coating inspection
Automotive inspection
Metal-processing inspection
Manufacturing quality control
Coating inspection
Surface-finishing inspection
Industrial maintenance
Product quality inspection
Workshop measurements
Incoming-material inspection

UNI-T identifies coating-thickness gauges as useful in areas including automobile manufacturing, vehicle evaluation, metal processing, coating and inspection. (UNI-T Meters)

Benefits of UNI-T UT343D

Wide Measuring Range

The UT343D measures coating thickness from 0 to 1250 µm, allowing it to handle a broad range of suitable coating applications. (UNI-T Meters)

Ferrous and Non-Ferrous Measurement

The instrument supports measurements on both ferrous and non-ferrous metal substrates. (UNI-T Meters)

Quick-Test Function

Its quick-test mode allows users to set a thickness range and use the three-colour LED and audio alarm to identify whether a measured coating falls within the preset range. (UNI-T Meters)

Data Storage

The UT343D can store up to 500 groups of measurement data, which can be useful when recording multiple inspection results. (UNI-T Meters)

PC Analysis

USB communication and PC analysis software allow stored measurements to be transferred for further analysis. (UNI-T Meters)

Portable Design

At approximately 175g, the UT343D is designed as a compact handheld measurement instrument. (UNI-T Meters)

Compatibility

The UNI-T UT343D is intended for measuring suitable coatings on metal substrates.

UNI-T explains that coating-thickness gauges can measure coatings such as paint, enamel, rubber, aluminium, chromium and copper in appropriate substrate configurations. The measured object should be metal and the coating should be non-conductive for the relevant measurement method. (UNI-T Meters)

Suitable applications can include:

Steel surfaces
Iron surfaces
Alloy surfaces
Aluminium surfaces
Copper surfaces
Painted metal
Coated metal
Non-conductive protective coatings

Always confirm the measurement conditions and substrate type before testing.

UNI-T UT343D Datasheet

Specification	UNI-T UT343D
Brand	UNI-T
Model	UT343D
Product Type	Coating Thickness Gauge
Measuring Range	0–1250 µm
Accuracy	±(3%H + 1) µm
Resolution	0.1 µm / 1 µm
Metal Type	Ferrous / Non-ferrous
Measurement Method	Single / Continuous
Measurement Mode	Max / Min / Average
Display	2.0-inch TFT LCD
Display Resolution	320 × 240 pixels
Data Storage	500 groups
Quick Test	Yes
LED Alarm	Yes
Audio Alarm	Yes
USB Communication	Yes
PC Software	Yes
Auto Power Off	Yes
Low Battery Indicator	Yes
Power	2 × 1.5V AA batteries
Weight	Approx. 175g
Dimensions	153.5 × 64.5 × 41mm

Specifications are based on UNI-T’s official UT343D documentation. (UNI-T Meters)

UNI-T UT343D vs UNI-T UT343A

Both instruments are coating thickness gauges designed for ferrous and non-ferrous materials, but their specifications differ.

Feature	UNI-T UT343D	UNI-T UT343A
Measuring range	0–1250 µm	0–1750 µm
Data storage	500 groups	199 groups
Display	2-inch TFT LCD	EBTN
USB communication	Yes	Not listed
PC analysis software	Yes	Not listed
Quick test	Yes	Not listed
Measurement modes	Max/Min/Avg	Max/Min/Avg
Ferrous/non-ferrous	Yes	Yes

UNI-T’s published specifications show that the UT343A has a wider maximum measuring range, while the UT343D provides features such as USB communication, PC analysis software, larger data storage and quick-test functionality. (UNI-T Meters)

UNI-T UT343D vs Basic Coating Thickness Gauge

Feature	UNI-T UT343D	Basic Gauge
Coating thickness measurement	Yes	Yes
Ferrous/non-ferrous support	Yes	Model-dependent
Continuous measurement	Yes	Model-dependent
Max/Min/Avg readings	Yes	Model-dependent
Data storage	500 groups	Often limited
USB communication	Yes	Model-dependent
PC analysis software	Yes	Often unavailable
Quick-test mode	Yes	Often unavailable
LED/audio alarms	Yes	Model-dependent

The UT343D can be advantageous where users need measurement records, quick testing and PC-based analysis in addition to basic thickness measurement.

Who Should Buy UNI-T UT343D?

The UNI-T UT343D may be suitable for:

Automotive inspection businesses
Metal-processing companies
Manufacturing businesses
Coating inspection professionals
Quality-control teams
Industrial maintenance teams
Workshops
Product inspection businesses
Surface-finishing operations
Engineering inspection applications

Where to Buy UNI-T UT343D in Nigeria

Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited

Call: 07049528019
WhatsApp: 09040054359
Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria.

Delivery: Same Day Delivery in Lagos. Same Day Shipping to Other States.

Nature Links Nigeria Limited supplies UNI-T coating thickness gauges, electrical test instruments, measuring equipment and inspection tools to customers across Nigeria. Contact the supplier to confirm the current UNI-T Coating Thickness Gauge UT343D Price in Nigeria, availability, specifications and delivery options.
