Compression Testing Machine (CTM)

Key Features of Compression Testing Machine (CTM)

Heavy-duty steel load frame

Hydraulic loading system

High-capacity compression testing

Digital or analogue load indication

Load cell or pressure measurement system

Accurate force measurement

Suitable for concrete cube and cylinder testing

Overload protection on applicable models

Emergency stop/safety features on applicable digital systems

Manual, semi-automatic or automatic operation options

Adjustable distance between compression platens

Durable compression platens

Microprocessor-controlled models available

Data storage and printing on selected digital models

Suitable for laboratory and construction-site quality control

Available in different capacities, including 1000 kN, 2000 kN and 3000 kN

Description
Reviews (0)

Description

Compression Testing Machine (CTM) Price in Nigeria

Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine Compression Testing Machines (CTM) and laboratory testing equipment in Nigeria, supplying CTM machines, concrete testing equipment, soil testing equipment and civil engineering laboratory instruments to customers across Nigeria.

Compression Testing Machine (CTM) Price in Nigeria

The Compression Testing Machine (CTM) Price in Nigeria depends mainly on the machine capacity, analogue or digital operation, automation level, manufacturer, accuracy, specifications and accessories included. Current Nigerian market listings show prices ranging from approximately ₦1,300,000 for some 1000 kN analogue machines to ₦10,800,000 for 3000 kN fully automated models. A 2000 kN digital CTM is currently listed around ₦3,000,000–₦5,500,000 in some Nigerian listings.

For an exact Compression Testing Machine (CTM) Price in Nigeria, buyers should confirm the required capacity and whether they need a manual, digital, semi-automatic or fully automatic model.

Compression Testing Machine (CTM) Price Range in Nigeria

CTM Type / Capacity| Approximate Price Range

1000 kN Analogue CTM| ₦1,300,000 – ₦3,600,000

2000 kN Digital CTM| ₦3,000,000 – ₦5,500,000

2000 kN Premium Digital CTM| ₦5,000,000 – ₦9,400,000+

3000 kN Digital/Automatic CTM| ₦4,500,000 – ₦10,800,000+

These are indicative Nigerian market prices rather than fixed quotations. For example, a 1000 kN analogue CTM has been listed at ₦1.6 million, a 2000 kN digital model at ₦3.5 million, and a 3000 kN fully automated model at ₦10.8 million.

What Is a Compression Testing Machine?

A Compression Testing Machine (CTM) is laboratory equipment used to determine the compressive strength of materials by applying controlled compressive force until the test specimen reaches failure or the required test condition.

CTMs are commonly used for testing concrete cubes, concrete cylinders, blocks, bricks, stones, cement-related materials and other construction materials.

Key Features of Compression Testing Machine (CTM)

– Heavy-duty steel load frame

– Hydraulic loading system

– High-capacity compression testing

– Digital or analogue load indication

– Load cell or pressure measurement system

– Accurate force measurement

– Suitable for concrete cube and cylinder testing

– Overload protection on applicable models

– Emergency stop/safety features on applicable digital systems

– Manual, semi-automatic or automatic operation options

– Adjustable distance between compression platens

– Durable compression platens

– Microprocessor-controlled models available

– Data storage and printing on selected digital models

– Suitable for laboratory and construction-site quality control

– Available in different capacities, including 1000 kN, 2000 kN and 3000 kN

Uses of Compression Testing Machine

The Compression Testing Machine (CTM) Price in Nigeria is an important consideration for laboratories, but buyers should also evaluate the machine according to its intended application.

Common uses include:

– Testing concrete compressive strength

– Testing concrete cubes

– Testing concrete cylinders

– Testing concrete blocks

– Testing bricks

– Testing building stones

– Testing cement-related materials

– Construction quality control

– Civil engineering research

– University and polytechnic laboratory experiments

– Road and bridge construction testing

– Building-material testing laboratories

A 2000 kN CTM, for example, is marketed for testing concrete, cement, bricks, fire-resistant bricks, engineering ceramics and building stones.

Benefits of Compression Testing Machine

Accurate Material Strength Testing

A CTM provides controlled compression force that allows laboratories and engineers to determine the compressive strength of construction materials.

Improves Construction Quality Control

Testing concrete and other construction materials helps engineers verify whether materials meet specified strength requirements before and during construction.

Available in Different Capacities

Buyers can select a machine based on their expected testing load, with common options including 1000 kN, 2000 kN and 3000 kN.

Digital Data Display

Digital CTMs can provide electronic force readings and, depending on the model, automatic calculation, data storage and printing. One Nigerian 2000 kN listing specifies digital readout, automatic calculation and printable test results.

Suitable for Professional Laboratories

CTMs are used by construction companies, engineering laboratories, educational institutions, consultants and material-testing facilities.

Compression Testing Machine Datasheet

Specifications differ according to manufacturer and capacity. The following is an example of specifications published for a 2000 kN digital CTM:

Specification| Example

Maximum Testing Capacity| 2000 kN

Measurement Range| 0–2000 kN

Accuracy| Approximately ±1%

Platen/Bearing Plate| 320 × 260 mm

Maximum Piston Stroke| Up to 90 mm on applicable models

Hydraulic System| Hydraulic loading

Display| Digital

Control| Digital/microprocessor on applicable models

Test Materials| Concrete, blocks, bricks and building materials

Power Supply| Model-dependent

A separate 2000 kN model specifies a 320 × 260 mm platen, 330 mm vertical clearance, 50 mm piston stroke and 40 MPa hydraulic pump pressure.

Important: Specifications vary between CTM models. Always request the manufacturer’s datasheet before purchasing.

1000 kN vs 2000 kN vs 3000 kN Compression Testing Machine

Feature| 1000 kN CTM| 2000 kN CTM| 3000 kN CTM

Maximum Load| 1000 kN| 2000 kN| 3000 kN

Typical Application| Concrete/material testing| Heavy concrete testing| High-capacity testing

Suitable for Labs| Yes| Yes| Yes

Cost| Lower| Medium–High| Higher

Space Requirement| Moderate| Higher| Higher

Best For| Smaller testing requirements| General professional testing| High-load applications

The correct capacity should be selected based on the specimen type, expected maximum compressive force and applicable testing standard—not simply the lowest available price.

Digital vs Analogue Compression Testing Machine

An analogue CTM can be a cost-effective choice for laboratories that require straightforward compression testing. Digital models offer additional convenience through electronic force display and, depending on the model, automatic calculations, data storage and printing.

For laboratories carrying out frequent tests and requiring easier documentation, a digital or automated CTM may provide greater operational convenience.

Compression Testing Machine Compatibility

Before purchasing a CTM, confirm:

– Required maximum testing capacity

– Concrete cube dimensions

– Cylinder dimensions

– Platen size

– Required testing standard

– Hydraulic system specification

– Electrical power requirement

– Laboratory floor space

– Digital or analogue control requirement

– Availability of spare parts

– Calibration requirements

– Installation and operator training

Some advanced machines are available with automatic loading control and data-processing systems, while simpler models use manual control.

Compression Testing Machine Standards

Depending on the application and machine model, CTMs may be designed to work with relevant ASTM, BS, EN, IS or other applicable testing standards. Some commercially listed 2000 kN machines reference ASTM standards, while other Nigerian laboratory suppliers advertise equipment for international testing requirements.

Always confirm the exact standard required by your project, laboratory or regulatory authority before ordering.

Where to Buy Compression Testing Machine in Nigeria

Nature Links Nigeria Limited supplies laboratory and engineering equipment to customers across Nigeria.

Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited

Call: 07049528019

WhatsApp: 09040054359

Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria

Delivery: Same Day Delivery in Lagos. Same Day Shipping to Other States.

Contact Nature Links Nigeria Limited to confirm the current Compression Testing Machine (CTM) Price in Nigeria, available capacity, model specifications, warranty, delivery and installation requirements.

Why Buy Compression Testing Machine from a Nigerian Supplier?

Buying from a local supplier can make it easier to arrange delivery, installation, technical assistance, calibration support and after-sales service. Nigerian laboratory-equipment suppliers also offer CTMs in different capacities and configurations for construction and educational laboratories.

Before paying, request the product datasheet, warranty information, calibration details, accessories included and applicable testing standards.
