Deye Hybrid Inverter 20kW |LV Battery Supported| (SUN-20K-SG05LP3-EU-SM2) – Three Phase

Key Features

100% Unbalanced Output: Supports 100% phase unbalanced output, allowing each phase to deliver up to 50% of the total rated power for versatile phase distribution.
Low-Voltage Safety Architecture: Works with safe 48V low-voltage battery banks (Lithium-ion or Lead-acid) featuring built-in transformer isolation design.
High Charge/Discharge Capacity: Massive maximum charging and discharging current up to 350A, enabling ultra-fast battery replenishment during short grid availability windows.
AC Coupling & Generator Integration: retrofits easily into existing solar installations via AC coupling and fully supports direct charging/storing from diesel or petrol generators.
Parallel Scalability: Supports up to 10 units in parallel for both on-grid and off-grid operations to scale total system output.
6 Programmable Time Periods: Allows flexible 6-time-slot scheduling for custom battery charging and discharging cycles based on peak/off-peak energy rates or utility schedules.
Dual MPPT Trackers: Features 2 MPPT trackers supporting up to 32,000W DC input power for solar array utilization.

Description
Reviews (0)

Description

Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine Deye in Nigeria, supplying Deye solar inverters and energy storage solutions to customers across Nigeria.

The Deye Hybrid Inverter 20kW |LV Battery Supported| (SUN-20K-SG05LP3-EU-SM2) – Three Phase represents a top-tier commercial and large-scale residential power solution engineered to handle Nigeria’s demanding grid dynamics. Operating on a low-voltage 48V battery architecture with transformer isolation design, this hybrid inverter delivers exceptional safety, high power density, and uninterrupted backup capabilities. Whether you need to run high-load industrial machines, multi-story commercial facilities, or heavy residential appliances, the Deye Hybrid Inverter 20kW |LV Battery Supported| (SUN-20K-SG05LP3-EU-SM2) – Three Phase provides high efficiency and seamless power integration.

Price Range

The current Deye Hybrid Inverter 20kW |LV Battery Supported| (SUN-20K-SG05LP3-EU-SM2) – Three Phase price in Nigeria ranges between ₦4,050,000 and ₦4,800,000, depending on current exchange rates, shipping logistics, and warranty packages. When making a purchase, always ensure you source directly from an authorized distributor like Nature Links Nigeria Limited to guarantee original factory quality and valid warranty coverage.

Uses

Commercial Buildings & Complexes: Powering office complexes, shopping plazas, schools, and medical facilities requiring three-phase stability.
Industrial & Factory Outlets: Supporting heavy motor loads, production machinery, and commercial air conditioning units.
Luxury Estates & Large Residential Villas: Providing whole-house uninterruptible backup power across 3-phase electrical layouts.
Agricultural & Remote Pumping Systems: Running high-capacity water pumps, cold storage units, and farm machinery off-grid or with generator synchronization.

Benefits

Reduced Fuel Expenses: Drastically reduces generator runtime and diesel bills by maximizing solar energy harvesting and storage efficiency.
Uninterrupted Operations: Instantaneous transfer switch prevents downtime during sudden utility grid outages.
Lower Battery Costs: Compatibility with low-voltage 48V battery systems significantly cuts down initial battery bank setup costs compared to high-voltage alternatives.
Enhanced Phase Management: Unbalanced output capability protects appliances by dynamically routing power where phase loads are heaviest.

Compatibility

The Deye Hybrid Inverter 20kW |LV Battery Supported| (SUN-20K-SG05LP3-EU-SM2) – Three Phase price in Nigeria offers exceptional value due to its wide-ranging ecosystem compatibility:

Batteries: Fully compatible with 48V Lithium-ion (LiFePO4) and Lead-acid battery banks with automatic BMS self-adaptation via CAN/RS485.
Solar Panels: High DC input voltage (up to 800V) makes it compatible with all modern mono-PERC, N-Type, and bifacial solar panel series.
Generators: Features dry contact ports for automatic generator start/stop control.

Technical Datasheet Overview

Specification Parameter	Value / Range
Model Number	SUN-20K-SG05LP3-EU-SM2
Rated AC Output Power	20,000 Watts (20kW)
Max. AC Output Power	22,000 VA
Battery Type / Voltage Range	Lithium-ion or Lead-acid / 40V – 60V
Max. Charge/Discharge Current	350A
Max. DC Input Power	32,000 W
Max. DC Input Voltage	800 V
MPPT Operating Voltage Range	160V – 650V
No. of MPPT Trackers	2 (2+2 strings)
Max. Efficiency / Protection	97.6% / IP65 Protection Rating

Deye 20kW vs. Competitors Comparison

Feature	Deye 20kW LV Hybrid (SUN-20K-SG05LP3-EU-SM2)	Standard 20kW High-Voltage Inverters
Battery Voltage Requirement	48V Low Voltage (Safer, Cheaper)	High Voltage (200V–500V+)
Phase Load Flexibility	100% Unbalanced Output (up to 50% per phase)	Strictly Balanced (33% max per phase)
Parallel Scaling	Up to 10 Units (On-grid/Off-grid)	Limited (Usually 2–4 Units)
Generator Support	Built-in Auto-Start & Direct Storing	Requires External Switchgear

Where to Buy

To get the best competitive market rate for the Deye Hybrid Inverter 20kW |LV Battery Supported| (SUN-20K-SG05LP3-EU-SM2) – Three Phase price in Nigeria, purchase directly from Nature Links Nigeria Limited.

Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited
Call: 07049528019
WhatsApp: 09040054359
Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria
Delivery Service: Same Day Delivery in Lagos | Same Day Shipping to Other States across Nigeria

10 Related Items & Price in Nigeria

Deye 12kW Three Phase Hybrid Inverter Price in Nigeria – ₦2,850,000
Deye 16kW Single Phase Hybrid Inverter Price in Nigeria – ₦3,400,000
Deye 50kW Three Phase High Voltage Hybrid Inverter Price in Nigeria – ₦9,500,000
Deye SE-F16 16kWh 51.2V Low Voltage Lithium Battery Price in Nigeria – ₦3,000,000
Felicity 15kWh 51.2V Lithium Ion Battery Price in Nigeria – ₦2,050,000
Growatt 20kW Three Phase On-Grid Inverter Price in Nigeria – ₦2,600,000
Huawei 100kW Smart Solar Inverter SUN2000 Price in Nigeria – ₦6,350,000
HZ Solar 51.2V 300Ah Deep-Cycle LiFePO4 Lithium Battery Price in Nigeria – ₦1,950,000
580W Bifacial Monocrystalline Solar Panel Price in Nigeria – ₦95,000
Blue Power 120A MPPT Charge Controller Price in Nigeria – ₦240,000

Conclusion

Investing in the Deye Hybrid Inverter 20kW |LV Battery Supported| (SUN-20K-SG05LP3-EU-SM2) – Three Phase price in Nigeria provides unmatched long-term value for commercial and industrial users seeking clean, resilient, and cost-effective solar energy. With its robust feature set—including 100% phase load balancing, fast 350A battery charging, and flexible 48V low-voltage integration—this inverter guarantees continuous operations even under harsh grid conditions. Contact Nature Links Nigeria Limited today at their Alaba International Market shop or via phone/WhatsApp for guaranteed genuine products, expert technical support, and rapid nationwide delivery.
